P1061317-002 Zebra ZXP Series 3 Card Printer Service Manual 99
5.1 Introduction
The following sections describe removing both major assemblies and, where applicable,
sub-assemblies and/or components that are considered replaceable.
In general, only removal directions are presented; unless otherwise noted, replacement would
be performed by reversing the removal steps. Replacement instructions for some items are not
presented; removal and replacement of these items are considered too obvious to warrant a
detailed description.
Spares Kits are listed in Appendix J.
Electric Shock Caution • Before performing any of the procedures in this section, set
the printer power to OFF (O) and disconnect the power cord.
Electrostatic Discharge Caution • All replacement procedures must be performed at a
static-free work station, an anti-static wrist strap must be worn and properly terminated, or
other appropriate protection must be used.
Caution • Before beginning any of the procedures that follow, read completely through
the procedure. If you do not have the specified tools, or if any step(s) seem beyond your
skill or experience level, do not attempt the procedure. You may cause additional damage
to the printer.
NOTE • Some of the photographs in this section may show additional parts removed in
addition to removals for the process being described.
5
Replacement Procedures
