Zebra ZXP Series 3 - 5.5.18 Lid

5: Replacement Procedures
Procedures
P1061317-002 Zebra ZXP Series 3 Card Printer Service Manual 137
5.5.18 Lid
Step 1. Locate the Lid.
Step 2. If not already done, remove the Printhead; see Printhead Assembly on page 105.
Step 3. Remove a retaining clip (arrow below) from one end of the shaft.
NOTE • This procedure uses Spare Kit # P1031925-235: KIT, INNER TOP ASSEMBLY.
