Zebra ZXP Series 3 Service Manual

P1061317-002 Zebra ZXP Series 3 Card Printer Service Manual 323
APPENDIX J
Spares List
Introduction
This Appendix lists the Spare, Part Kits, Special Tools, and Upgrade Kits available for the
ZXP Series 3 Card Printer.
Before ordering, be sure to check the Partner Zone on
www.zebra.com for the latest Spare,
part kits listing.
Kit, # Description
P1031925-001 KIT ETHERNET PCBA
P1031925-007 KIT MLB SINGLE-SIDED
P1031925-008 KIT MLB DUAL-SIDED
P1031925-009 KIT CRYPTOGRAPHIC PCBA
P1031925-010 KIT LCDISPLAY PCBA
P1031925-011 KIT MAG HEAD REPLACEMENT
P1031925-012 KIT RIBBON SENSOR
P1031925-013 KIT MAG HEAD WITH SENSOR
P1031925-014 KIT ATM SENSOR
P1031925-015 KIT LID & RIBBON ENCODER SENSORS
P1031925-016 KIT SENSOR SMART CARD
P1031925-018 KIT MOTOR HEAD LIFT
P1031925-019 KIT MOTOR FOR RIBBON
P1031925-021 KIT SPRINGS FOR LINKAGE
P1031925-023 KIT RIBBON DRIVE SYSTEM
P1031925-025 KIT BELTS & O-RINGS FOR PRINT ENGINE
P1031925-026 KIT ENCODER DISK
Continued on next page

Zebra ZXP Series 3 Specifications

General

Color	No
Card size	54 x 86 mm
Card types	Magnetic stripe (ISO 7811), PVC, PVC Composite, Smart card
Card feeder	Yes
Print technology	Dye-sublimation
Maximum resolution	300 DPI
Print speed (color)	180 card/h
Print speed (monochrome)	750 card/h
Printing media thickness	762 µm
Duplex print speed (color)	140 card/h
Display	LCD
Certification	FCC, CE, UL, CUL
Product color	Grey, White
Internal memory	32 MB
Built-in barcodes	EAN13, EAN8, Interleaved 2/5, PDF417, UPC-A
Total input capacity	100 sheets
Display number of characters	16
Compatible operating systems	Windows
Storage temperature (T-T)	-5 - 70 °C
Operating temperature (T-T)	15 - 30 °C
Storage relative humidity (H-H)	20 - 70 %
Operating relative humidity (H-H)	20 - 65 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Interface	USB
Optional connectivity	Ethernet, USB 2.0

Weight and Dimensions

Weight	5530 g
Dimensions (WxDxH)	201 x 368 x 309 mm
