Zebra ZXP Series 3 Service Manual

324 Zebra ZXP Series 3 Card Printer Service Manual P1061317-002
J: Spares List
* Refer to Appendix M for ordering the correct printhead kit.
P1031925-029 KIT CLEANING ROLLER ASSEMBLY
P1031925-034 KIT PULLEY BELT FOR SMART CARD
P1031925-036 KIT LOCK REPLACEMENT
P1031925-038 KIT LATCH FOR FEEDER
P1031925-040 KIT GROUND PLATE
P1031925-042 KIT COVER FOR FEEDER
P1031925-045 KIT OUTPUT HOPPER ENCODING
P1031925-046 KIT FEET FOR PRINTER
P1031925-047 KIT COVERS FOR FRAME
P1031925-048 KIT CABLES ELECTRONICS
P1031925-049 KIT POWER SUPPLY
P1031925-050 KIT PACKAGING
P1031925-051 KIT SHIP AWAY
P1031925-052 KIT MISCELLANEOUS HARDWARE
P1031925-053 KIT SENSOR FEEDER COVER
P1031925-054 KIT SYNC SENSOR
P1031925-055 KIT FLIPPER SENSOR
KIT PRINTHEAD*
P1031925-071 KIT COOLING FANS
P1031925-072 KIT DRIVE LINKAGE
P1031925-073 KIT DRIVE GEARS & CAMSHAFT
P1031925-074 KIT PRESSURE ROLLERS
P1031925-075 KIT UPGRADE MAG ENCODER
P1031925-076 KIT FLIPPER ASSEMBLY
P1031925-077 KIT UPGRADE MANUAL CARD FEED
P1031925-203 KIT UPGRADE CONACT STATION
P1031925-204 KIT UPGRADE MIFARE & CONTACT
P1031925-205 KIT UPGRADE SECURITY
P1031925-217 KIT MOTOR CARD DRIVE
P1031925-224 KIT DRIVE SYSTEM
P1031925-228 KIT PLATENS FOR PRINT ENG
P1031925-230 KIT FEEDER ASSEMBLY
P1031925-233 KIT CARRIER AND DRIVE FOR FLIPPER
P1031925-235 KIT INNER TOP ASSY
P1031925-237 KIT BUTTON FOR DOOR
P1031925-241 KIT TOP COVER BADGE
P1031925-243 KIT SIDE PANELS BEZELS
P1031925-244 KIT OUTPUT HOPPER NON-ENCODE
Kit, # Description

Zebra ZXP Series 3 Specifications

General

Color	No
Card size	54 x 86 mm
Card types	Magnetic stripe (ISO 7811), PVC, PVC Composite, Smart card
Card feeder	Yes
Print technology	Dye-sublimation
Maximum resolution	300 DPI
Print speed (color)	180 card/h
Print speed (monochrome)	750 card/h
Printing media thickness	762 µm
Duplex print speed (color)	140 card/h
Display	LCD
Certification	FCC, CE, UL, CUL
Product color	Grey, White
Internal memory	32 MB
Built-in barcodes	EAN13, EAN8, Interleaved 2/5, PDF417, UPC-A
Total input capacity	100 sheets
Display number of characters	16
Compatible operating systems	Windows
Storage temperature (T-T)	-5 - 70 °C
Operating temperature (T-T)	15 - 30 °C
Storage relative humidity (H-H)	20 - 70 %
Operating relative humidity (H-H)	20 - 65 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Interface	USB
Optional connectivity	Ethernet, USB 2.0

Weight and Dimensions

Weight	5530 g
Dimensions (WxDxH)	201 x 368 x 309 mm
