P1061317-002 Zebra ZXP Series 3 Card Printer Service Manual 87
4
Troubleshooting
4.1 Introduction
The objective of troubleshooting is to relate a problem to an associated assembly or system
function, in order to most efficiently isolate and repair the problem. Typically this involves
determining the failure symptom and then checking one or more possible causes of the failure.
Only a symptom-related list of possibilities appears. In general, for a given failure symptom
one or more possible causes are listed, with suggested corrective action to take. These causes
should be checked and corrective actions taken in the order given; they are listed in order of
likelihood and complexity.
When the suggestions presented fail to lead to a repair, a
CPU Board replacement, if not
prescribed, should nevertheless be tried. A check for broken or disconnected cables and any
loss of power should also take place along with checks for obvious mechanical damage.
Zebra Card Printer solutions offers Technical Support and factory repair as options.

Zebra ZXP Series 3 Specifications

General

Color	No
Card size	54 x 86 mm
Card types	Magnetic stripe (ISO 7811), PVC, PVC Composite, Smart card
Card feeder	Yes
Print technology	Dye-sublimation
Maximum resolution	300 DPI
Print speed (color)	180 card/h
Print speed (monochrome)	750 card/h
Printing media thickness	762 µm
Duplex print speed (color)	140 card/h
Display	LCD
Certification	FCC, CE, UL, CUL
Product color	Grey, White
Internal memory	32 MB
Built-in barcodes	EAN13, EAN8, Interleaved 2/5, PDF417, UPC-A
Total input capacity	100 sheets
Display number of characters	16
Compatible operating systems	Windows
Storage temperature (T-T)	-5 - 70 °C
Operating temperature (T-T)	15 - 30 °C
Storage relative humidity (H-H)	20 - 70 %
Operating relative humidity (H-H)	20 - 65 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Interface	USB
Optional connectivity	Ethernet, USB 2.0

Weight and Dimensions

Weight	5530 g
Dimensions (WxDxH)	201 x 368 x 309 mm
