Zebra ZXP Series 3 Service Manual

2: Installation and Setup
Installing the Windows Printer Driver
P1061317-002 Zebra ZXP Series 3 Card Printer Service Manual 31
2.7.3 Setting Up a Network Printer
Use this procedure if you have already installed an Ethernet printer on your system (refer
to Ethernet Driver Installation on page 26), and you want to install a second Ethernet printer
on the network via the Microsoft Add Printer Wizard.
Step 1. Click on the Start button, then select Devices and Printers.
Step 2. Observe the Devices and Printers window.
Step 3. Click on the Add a printer option in the Taskbar (arrow above).
Step 4. Observe the What type of printer do you want to install window.
Step 5. Select Add a local printer (arrow above), and click the Next button.

Zebra ZXP Series 3 Specifications

General

Color	No
Card size	54 x 86 mm
Card types	Magnetic stripe (ISO 7811), PVC, PVC Composite, Smart card
Card feeder	Yes
Print technology	Dye-sublimation
Maximum resolution	300 DPI
Print speed (color)	180 card/h
Print speed (monochrome)	750 card/h
Printing media thickness	762 µm
Duplex print speed (color)	140 card/h
Display	LCD
Certification	FCC, CE, UL, CUL
Product color	Grey, White
Internal memory	32 MB
Built-in barcodes	EAN13, EAN8, Interleaved 2/5, PDF417, UPC-A
Total input capacity	100 sheets
Display number of characters	16
Compatible operating systems	Windows
Storage temperature (T-T)	-5 - 70 °C
Operating temperature (T-T)	15 - 30 °C
Storage relative humidity (H-H)	20 - 70 %
Operating relative humidity (H-H)	20 - 65 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Interface	USB
Optional connectivity	Ethernet, USB 2.0

Weight and Dimensions

Weight	5530 g
Dimensions (WxDxH)	201 x 368 x 309 mm
