5: Replacement Procedures
Procedures
P1061317-002 Zebra ZXP Series 3 Card Printer Service Manual 141
Step 3. With a TORX T10 driver, remove the four screws (SCR, PLAST, 4-.37L, 9.0 lb),
two on each side, holding the Flipper Module to the Frame; circled below.
Step 4. Cut the cable ties holding the various cables and connectors.
Step 5. Remove the Flipper Module.
