Zebra ZXP Series 3 Service Manual

194 Zebra ZXP Series 3 Card Printer Service Manual P1061317-002
A: Model Numbers
The Part Number of a particular Zebra ZXP Series 3 Card Printer is shown on a label affixed to
the bottom of the printer; that Part Number identifies the specific configuration for that printer.
This chart shows the configurations that are available:
PART NUMBER DESCRIPTION
Z3_ -____________ BASE UNIT
__1-_____2______ Single-Sided
__2-_____2______ Double-Sided
SMART CARD OPTIONS
___-0____2______ None
___-A____2______ PC/SC Contact Encoder + Contactless MIFARE, see NOTE
___-E____2______ Contact Station, NOTE
MAG ENCODER OPTIONS
___-_0__________ None
___-_M___2______ ISO HiCo/LoCo Mag S/W-selectable
SECURITY OPTIONS, NOTE
___-__0_________ None
___-0_A_________ Enclosure Lock: Includes 2 keys, and Output Bin cover
___ -A_A_________ Enclosure Lock: Includes 2 keys, and Output Bin with cover
___ -E_A_________ Enclosure Lock: Includes 2 keys, and Output Bin with cover
INTERFACE OPTIONS
___-___0________ USB Only
___-___C________ USB & 10/100 Ethernet, see NOTE
SOFTWARE / KIT
___-____0_______ None
___-____G_______
Starter Kit: Monochrome ( Incl: 1 Monochrome Ribbon,
200 PVC Cards )
___-____H_______ Starter Kit: Color ( Incl: 1 YMCKO Ribbon, 200 PVC Cards )
___-____I_______
Starter Kit: Dual-Sided Color ( Incl: 1 YMCKOK Ribbon,
200 PVC Cards )
MISCELLANEOUS
___-_____000____ None
___-_____2______ ZXP Series 3 Release 2.0
COUNTRY CODE (power cord option)
___-________00__ No power cords
___-________AP__ Britain
___-________US__ Americas
___-________BR__ Brazil
_ _ _ - _ _ _ _ _ _ _ _ E M _ _ EMEA (Europe, the Middle East, and Africa)
___-________CN00 China
___-________IN00 India
CUSTOM CODE
___-__________00 State / Province / Project / Other
ACCESSORIES
105862-001 CardSense
TM
single card feed option, see NOTE
105999-301 Cleaning Kit: 4 printer-path and 4 feeder cleaning cards
NOTE: Field-Upgradeable Option

Zebra ZXP Series 3 Specifications

General

Color	No
Card size	54 x 86 mm
Card types	Magnetic stripe (ISO 7811), PVC, PVC Composite, Smart card
Card feeder	Yes
Print technology	Dye-sublimation
Maximum resolution	300 DPI
Print speed (color)	180 card/h
Print speed (monochrome)	750 card/h
Printing media thickness	762 µm
Duplex print speed (color)	140 card/h
Display	LCD
Certification	FCC, CE, UL, CUL
Product color	Grey, White
Internal memory	32 MB
Built-in barcodes	EAN13, EAN8, Interleaved 2/5, PDF417, UPC-A
Total input capacity	100 sheets
Display number of characters	16
Compatible operating systems	Windows
Storage temperature (T-T)	-5 - 70 °C
Operating temperature (T-T)	15 - 30 °C
Storage relative humidity (H-H)	20 - 70 %
Operating relative humidity (H-H)	20 - 65 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Interface	USB
Optional connectivity	Ethernet, USB 2.0

Weight and Dimensions

Weight	5530 g
Dimensions (WxDxH)	201 x 368 x 309 mm
