Zebra ZXP Series 3 Service Manual

280 Zebra ZXP Series 3 Card Printer Service Manual P1061317-002
H: Upgrade Kit Instructions
Contact Station
Parts List
Special Tools
• TORX T6 and T10 Drivers
• Flat-blade Screwdriver
• 5.5mm Nut Driver
• Small Diagonal Cutters or other cutter for cutting cable ties
Procedure
UPGRADE KIT: P1031925-203; KIT, UPGRADE, CONACT STATN
QTY PART NUMBER DESCRIPTION
1 P1027093-004 KIT,CNTCT STN,ZXP3,R2
4 806597G-404 SCR,PH,TORX,PLAST,4-.25L,ZN
1 P1027713 CARD CATCHER BASE, ZXP3
1 P1027714 CARD CATCHER BASKET,ZXP3
4 806822-001 FOOT,CYLINDRICAL,ADH-BACKED
1 806597G-406 SCR,PH,TORX,PLAST,6-.25L,ZN
1 807019-004 CABLE TIE,LOCKING,3.9",NYLON
1 P1026176-002 ENCLOSURE,FRONT,ENCODE,ZXP3 R2.0
Electric Shock Caution • Before performing any of the procedures in this section, set
the printer power to OFF (O) and disconnect the power cord.
Electrostatic Discharge Caution • This replacement procedure must be performed at a
static-free work station, an anti-static wrist strap must be worn and properly terminated,
or other appropriate protection must be used.
Caution • Before beginning any of the steps that follow, read completely through this
procedure. If you do not have the specified tools, or if any step(s) seem beyond your skill
or experience level, do not attempt the procedure. You may cause additional damage to
the printer.

Zebra ZXP Series 3 Specifications

General

Color	No
Card size	54 x 86 mm
Card types	Magnetic stripe (ISO 7811), PVC, PVC Composite, Smart card
Card feeder	Yes
Print technology	Dye-sublimation
Maximum resolution	300 DPI
Print speed (color)	180 card/h
Print speed (monochrome)	750 card/h
Printing media thickness	762 µm
Duplex print speed (color)	140 card/h
Display	LCD
Certification	FCC, CE, UL, CUL
Product color	Grey, White
Internal memory	32 MB
Built-in barcodes	EAN13, EAN8, Interleaved 2/5, PDF417, UPC-A
Total input capacity	100 sheets
Display number of characters	16
Compatible operating systems	Windows
Storage temperature (T-T)	-5 - 70 °C
Operating temperature (T-T)	15 - 30 °C
Storage relative humidity (H-H)	20 - 70 %
Operating relative humidity (H-H)	20 - 65 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Interface	USB
Optional connectivity	Ethernet, USB 2.0

Weight and Dimensions

Weight	5530 g
Dimensions (WxDxH)	201 x 368 x 309 mm
