236 Parameters
AI1 Speed reference from analogue input AI1. 1
AI2 Speed reference from analogue input AI2. 2
FBA REF1 Speed reference from fieldbus reference 1. 3
FBA REF2 Speed reference from fieldbus reference 2. 4
EFB REF1 Speed reference from EFB reference 1. 5
EFB REF2 Speed reference from EFB reference 2. 6
22.05 SPEED SCALING
Internally used. Cannot be set by the user.
Shows the motor rotational speed (rpm), which
corresponds to the lift nominal speed (m/s) defined
with parameter 80.01 NOMINAL SPEED. The
parameter value is calculated based on the lift
nominal speed, gear ratio, roping ratio and sheave
diameter. See also section Speed reference scaling
on page 142.
Also defines the rpm value that corresponds to
20000 for fieldbus communication with ABB Drives
communication profile.
- / Real
0...30000 rpm Speed scaling value. 1 = 1 rpm
22.06 EM STOP TIME
Defines the time within which the drive is stopped if
an emergency stop OFF3 is activated (ie, the time
required for the speed to change from the speed
value defined by parameter 22.05 SPEED SCALING
to zero). The emergency stop OFF3 is activated if the
Final limit switches or Leveling overtime stop function
becomes active. See also section Emergency stop
on page 169.
Emergency stop OFF1 uses the active ramp time.
1.000 s /
Real
0.000…
1800.000 s
Emergency stop OFF3 deceleration time. - /
1000 = 1 s
25
25 ACC/DEC
RAMP
Speed reference ramp settings.
25.80 ACC/DEC SEL
Selects the source for the acceleration/deceleration
set 1 or acceleration/deceleration set 2 used in the
normal travel mode.
1 = Acc/dec set 2 is used.
0 = Acc/dec set 1 is used.
For more information, see section
Acceleration/deceleration selection on page 144.
C.False/
Bit pointer
Bit pointer: CONST or POINTER (See Terms and
abbreviations on page 183.)
No. Bit/Name/Value/
Range
Description Def/Type
FbEq
(16b/32b)
