252 Parameters
50.03 COMM LOSS T
OUT
Defines the time delay before the action defined by
parameter 50.02 COMM LOSS FUNC is taken. Time
count starts when the link fails to update the
message.
0.3 s /
UINT32
0.3…6553.5 s Delay for fieldbus communication loss function. 10 = 1 s / -
50.04 FBA REF1
MODESEL
Selects the fieldbus reference FBA REF1 scaling and
the actual value, which is sent to the fieldbus (FBA
ACT1).
Speed /
enum
Raw data No scaling (ie, data is transmitted without scaling).
The source for the actual value, which is sent to the
fieldbus, is selected by parameter 50.06 FBA ACT1
TR SRC.
0
Torque Fieldbus adapter module uses torque reference
scaling. Torque reference scaling is defined by the
used fieldbus profile (eg, with ABB Drives Profile,
integer value 10000 corresponds to 100% torque
value). Signal 01.06 TORQUE is sent to the fieldbus
as an actual value. See the User’s manual of the
appropriate fieldbus adapter module.
1
Speed Fieldbus adapter module uses speed reference
scaling. Speed reference scaling is defined by the
used fieldbus profile (eg, with ABB Drives Profile,
integer value 20000 corresponds to the value of
parameter 22.05 SPEED SCALING). Signal 01.01
SPEED ACT is sent to the fieldbus as an actual
value. See the User’s manual of the appropriate
fieldbus adapter module.
2
50.05 FBA REF2
MODESEL
Selects the fieldbus reference FBA REF2 scaling. Speed /
enum
See parameter 50.04 FBA REF1 MODESEL. 1 = 1 / -
50.06 FBA ACT1 TR SRC
Selects the source for fieldbus actual value 1 when
parameter 50.04 FBA REF1 MODESEL / 50.05 FBA
REF2 MODESEL is set to Raw data.
See signal 01.01 SPEED ACT.
P.SPEED
ACT/
Val pointer
Value pointer (See Terms and abbreviations on
page 183.)
50.07 FBA ACT2 TR SRC
Selects the source for fieldbus actual value 2 when
parameter 50.04 FBA REF1 MODESEL / 50.05 FBA
REF2 MODESEL is set to Raw data.
See signal 01.06 TORQUE.
P. TO RQ U E /
Val pointer
Value pointer (See Terms and abbreviations on
page 183.)
No. Bit/Name/Value/
Range
Description Def/Type
FbEq
(16b/32b)
