11. Timer 0/1/2 A96G166/A96A166/A96S166 User’s manual
102
11.2.6 Register map
Table 18. TIMER 1 Register Map
Name
Address
Direction
Default
Description
T1CRL
BAH
R/W
00H
Timer 1 Control Low Register
T1CRH
BBH
R/W
00H
Timer 1 Control High Register
T1ADRL
BCH
R/W
FFH
Timer 1 A Data Low Register
T1ADRH
BDH
R/W
FFH
Timer 1 A Data High Register
T1BDRL
BEH
R/W
FFH
Timer 1 B Data Low Register
T1BDRH
BFH
R/W
FFH
Timer 1 B Data High Register
T1CDRL
D9H
R/W
FFH
Timer 1 C Data Low Register
T1CDRH
DAH
R/W
FFH
Timer 1 C Data High Register
T1DDRL
DBH
R/W
FFH
Timer 1 D Data Low Register
T1DDRH
DCH
R/W
FFH
Timer 1 D Data High Register
11.2.7 Register description
T1ADRH (Timer 1 A data High Register): BDH
7
6
5
4
3
2
1
0
T1ADRH7
T1ADRH6
T1ADRH5
T1ADRH4
T1ADRH3
T1ADRH2
T1ADRH1
T1ADRH0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: FFH
T1ADRH[7:0]
T1 A Data High Byte
T1ADRL (Timer 1 A Data Low Register): BCH
7
6
5
4
3
2
1
0
T1ADRL7
T1ADRL6
T1ADRL5
T1ADRL4
T1ADRL3
T1ADRL2
T1ADRL1
T1ADRL0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: FFH
T1ADRL[7:0]
T1 A Data Low Byte
NOTE: Do not write “0000H” in the T1ADRH/T1ADRL register
when PPG mode
T1BDRH (Timer 1 B Data High Register): BFH
7
6
5
4
3
2
1
0
T1BDRH7
T1BDRH6
T1BDRH5
T1BDRH4
T1BDRH3
T1BDRH2
T1BDRH1
T1BDRH0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: FFH
T1BDRH[7:0]
T1 B Data High Byte
