A96G166/A96A166/A96S166 User’s manual 6. Interrupt controller
65
6.11.6 Interrupt register description
IE (Interrupt Enable Register): A8H
7
6
5
4
3
2
1
0
EA
–
INT5E
–
–
INT2E
INT1E
INT0E
R/W
–
R/W
–
–
R/W
R/W
R/W
Initial value: 00H
EA
Enable or Disable All Interrupt bits
0
All Interrupt disable
1
All Interrupt enable
INT5E
Enable or Disable External Interrupt 0 ~ 4 (EINT0 ~ EINT4)
0
Disable
1
Enable
INT2E
Enable or Disable External Interrupt 12 (EINT12)
0
Disable
1
Enable
INT1E
Enable or Disable External Interrupt 11(EINT11)
0
Disable
1
Enable
INT0E
Enable or Disable External Interrupt 10 (EINT10)
0
Disable
1
Enable
IE1 (Interrupt Enable Register 1): A9H
7
6
5
4
3
2
1
0
–
–
INT11E
INT10E
INT9E
INT8E
INT7E
INT6E
–
–
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: 00H
INT11E
Enable or Disable USART0 RX Interrupt
0
Disable
1
Enable
INT10E
Enable or Disable USART1 TX Interrupt
0
Disable
1
Enable
INT9E
Enable or Disable USART1 RX Interrupt
0
Disable
1
Enable
INT8E
Enable or Disable I2C Interrupt
0
Disable
1
Enable
INT7E
Enable or Disable External Interrupt 6 (EINT6)
0
Disable
1
Enable
INT6E
Enable or Disable External Interrupt 5 (EINT5)
0
Disable
1
Enable
