6. Interrupt controller A96G166/A96A166/A96S166 User’s manual
66
IE2 (Interrupt Enable Register 2): AAH
7
6
5
4
3
2
1
0
–-
–
INT17E
–
INT15E
INT14E
INT13E
INT12E
–
–
R/W
–
R/W
R/W
R/W
R/W
Initial value: 00H
INT17E
Enable or Disable External Interrupt 7 ~ A (EINT7 ~ EINTA)
0
Disable
1
Enable
INT15E
Enable or Disable Timer 2 Match Interrupt
0
Disable
1
Enable
INT14E
Enable or Disable Timer 1 Match Interrupt
0
Disable
1
Enable
INT13E
Enable or Disable Timer 0 Match Interrupt
0
Disable
1
Enable
INT12E
Enable or Disable USART0 TX Interrupt
0
Disable
1
Enable
IE3 (Interrupt Enable Register 3): ABH
7
6
5
4
3
2
1
0
–
–
INT23E
INT22E
INT21E
INT20E
INT19E
INT18E
–
–
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: 00H
INT23E
Enable or Disable LVI Interrupt
0
Disable
1
Enable
INT22E
Enable or Disable BIT Interrupt
0
Disable
1
Enable
INT21E
Enable or Disable WDT Interrupt
0
Disable
1
Enable
INT20E
Enable or Disable WT Interrupt
0
Disable
1
Enable
INT19E
Enable or Disable CRC Interrupt
0
Disable
1
Enable
INT18E
Enable or Disable ADC Interrupt
0
Disable
1
Enable
IP (Interrupt Priority Register): B8H
7
6
5
4
3
2
1
0
–
–
IP5
IP4
IP3
IP2
IP1
IP0
–
–
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: 00H
