A96G166/A96A166/A96S166 User’s manual 17. Power down operation

171

17.5 Register map

Table 33. Power-down Operation Register Map

Name

Address

Direction

Default

Description

PCON

87H

R/W

00H

Power Control Register

17.6 Register description

PCON (Power Control Register): 87H

PCON7

–

PCON3

PCON2

PCON1

PCON0

R/W

–

R/W

Initial value: 00H

PCON[7:0]

Power Control

01H

IDLE mode enable

03H

STOP mode enable

Other

Values

Normal operation

NOTES:

1. To enter into IDLE mode, PCON must be set to ‘01H’.

2. To enter into STOP mode, PCON must be set to ‘03H’.

3. The PCON register is automatically cleared by a release signal in STOP/IDLE mode. Three or more

NOP instructions must immediately follow the instruction that make the device enter into STOP/IDLE

mode. Refer to the following examples code.

Example 1

Example 2

MOV PCON, #01H ; IDLE mode

NOP

MOV PCON, #03H ; STOP mode

NOP
