6. Interrupt controller A96G166/A96A166/A96S166 User’s manual

6.11.5 Register map

Table 9. Interrupt Register Map

Name

Address

Direction

Default

Description

A8H

R/W

00H

Interrupt Enable Register

IE1

A9H

R/W

00H

Interrupt Enable Register 1

IE2

AAH

R/W

00H

Interrupt Enable Register 2

IE3

ABH

R/W

00H

Interrupt Enable Register 3

B8H

R/W

00H

Interrupt Priority Register

IP1

F8H

R/W

00H

Interrupt Priority Register 1

EIFLAG0

C0H

R/W

00H

External Interrupt Flag 0 Register

EIPOL0L

A4H

R/W

00H

External Interrupt Polarity 0 Low Register

EIPOL0H

A5H

R/W

00H

External Interrupt Polarity 0 High Register

EIFLAG1

A6H

R/W

00H

External Interrupt Flag 1 Register

EIPOL1

A7H

R/W

00H

External Interrupt Polarity 1 Register

EIPOL2

A3H

R/W

00H

External Interrupt Polarity 2 Register
