13. 12-bit ADC A96G166/A96A166/A96S166 User’s manual

120

13.4 Register map

Table 23. ADC Register Map

Name

Address

Direction

Default

Description

ADCDRH

9FH

xxH

A/D Converter Data High Register

ADCDRL

9EH

xxH

A/D Converter Data Low Register

ADCCRH

9DH

R/W

01H

A/D Converter Control High Register

ADCCRL

9CH

R/W

00H

A/D Converter Control Low Register

13.5 Register description

ADCDRH (A/D Converter Data High Register):9FH

ADDM11

ADDM10

ADDM9

ADDM8

ADDM7

ADDL11

ADDM6

ADDL10

ADDM5

ADDL9

ADDM4

ADDL8

Initial value: xxH

ADDM[11:4]

MSB align, A/D Converter High Data (8-bit)

ADDL[11:8]

LSB align, A/D Converter High Data (4-bit)

ADCDRL (A/D Converter Data Low Register): 9EH

ADDM3

ADDL7

ADDM2

ADDL6

ADDM1

ADDL5

ADDM0

ADDL4

ADDL3

ADDL2

ADDL1

ADDL0

R-

Initial value: xxH

ADDM[3:0]

MSB align, A/D Converter Low Data (4-bit)

ADDL[7:0]

LSB align, A/D Converter Low Data (8-bit)
