A96G166/A96A166/A96S166 User’s manual 18. Reset

175

Table 35. Boot Process Description

Process

Description

Remarks

①

 No Operation

 LSI (128kHz) ON

0.7V to 0.9V

②

1st POR level Detection

About 1.1V to 1.3V

③

 (LSI 128kHz/32)x32h Delay section

(=10ms)

 VDD input voltage must rise over than

flash operating voltage for Configure

option read

Slew Rate  0.025V/ms

④

Configure option read point

 About 1.6V to 1.8V

 Configure Value is determined by

Writing Option

⑤

Rising section to Reset Release Level

16ms point after POR or Ext_reset

release

⑥

Reset Release section (BIT overflow)

I. After 16ms, after External Reset

Release (External reset)

II. 16ms point after POR (POR only)

BIT is used for Peripheral stability

⑦

Normal operation
