A96G166/A96A166/A96S166 User’s manual 16. CRC
165
CRC_MNT_L (CRC Monitor Low Register): 1075H
7
6
5
4
3
2
1
0
CRC_MNT[7]
CRC_MNT[6]
CRC_MNT[5]
CRC_MNT[4]
CRC_MNT[3]
CRC_MNT[2]
CRC_MNT[1]
CRC_MNT[0]
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: 00H
CRC_MNT
[15:0]
CRC compare register, when performing a validate
CRC_ADDR_START_H (CRC Start Address High Register): 1079H
7
6
5
4
3
2
1
0
-
-
-
-
-
-
-
CRC_ADDR_
START[16]
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: 00H
CRC_ADDR_START_M (CRC Start Address Middle Register): 107AH
7
6
5
4
3
2
1
0
CRC_ADDR_
START[15]
CRC_ADDR_
START[14]
CRC_ADDR_
START[13]
CRC_ADDR_
START[12]
CRC_ADDR_
START[11]
CRC_ADDR_
START[10]
CRC_ADDR_
START[9]
CRC_ADDR_
START[8]
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: 00H
CRC_ADDR_START_L (CRC Start Address Low Register): 107BH
7
6
5
4
3
2
1
0
CRC_ADDR_
START[7]
CRC_ADDR_
START[6]
CRC_ADDR_
START[5]
CRC_ADDR_
START[4]
CRC_ADDR_
START[3]
CRC_ADDR_
START[2]
CRC_ADDR_
START[1]
CRC_ADDR_
START[0]
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: 00H
CRC_ADDR_
START[16:0]
CRC start address
CRC_ADDR_END_H (CRC END Address High Register): 107CH
7
6
5
4
3
2
1
0
-
-
-
-
-
-
-
CRC_ADDR_END[16]
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: 00H
CRC_ADDR_END_M (CRC END Address Middle Register): 107DH
7
6
5
4
3
2
1
0
CRC_ADDR_
END[15]
CRC_ADDR_
END[14]
CRC_ADDR_
END[13]
CRC_ADDR_
END[12]
CRC_ADDR_
END[11]
CRC_ADDR_
END[10]
CRC_ADDR_
END[9]
CRC_ADDR_
END[8]
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: 00H
