8. Start program. FECR:0000_1011

9. Insert one NOP operation

10. Read FESR until PEVBSY is 1.

Flash OTP area erase mode

1. Enable program mode.

2. Reset page buffer. FEMR: 1000_0001 FECR:0000_0010

3. Select page buffer. FEMR:1000_1001

4. Write ‘h00 to page buffer. (Data value is not important.)

5. Set erase mode and select OTP area. FEMR:1001_0101

6. Set page address. FEARH:FEARM:FEARL=20’hx_xxxx

7. Set FETCR.

8. Start erase. FECR:0000_1011

9. Insert one NOP operation

10. Read FESR until PEVBSY is 1.

Flash program verify mode

1. Enable program mode.

2. Set program verify mode. FEMR:1010_0011

3. Read data from Flash.

OTP program verify mode

1. Enable program mode.

2. Set program verify mode. FEMR:1010_0111

3. Read data from Flash.

Flash erase verify mode

1. Enable program mode.

2. Set erase verify mode. FEMR:1001_0011

3. Read data from Flash
