A96G166/A96A166/A96S166 User’s manual 5. I/O ports

P3FSRH (Port 3 Function Selection High Register): 9BH

P3FSRH2

P3FSRH1

P3FSRH0

R/W

Initial value: 00H

P3FSRH2

P37 Function select

I/O Port

XOUT Function

P3FSRH1

P36 Function Select

I/O Port

XIN Function

P3FSRH0

P35 Function select

I/O Port (EINT10 function possible when input)

T0O/PWM0O Function

P3FSRL (Port 3 Function Selection Low Register): 9AH

P3FSRL6

P3FSRL5

P3FSRL4

P3FSRL3

P3FSRL2

P3FSRL1

P3FSRL0

R/W

Initial value: 00H

P3FSRL6

P34 Function select

I/O Port

SXIN Function

P3FSRL5

P33 Function Select

I/O Port

SXOUT Function

P3FSRL4

P32 Function select

I/O Port

T0O/PWM0O Function

P3FSRL[3:2]

P31 Function select

P3FSRL3

P3FSRL2

Description

I/O Port

RXD1/MISO1 Function

SCL Function

EC0 Function

P3FSRL[1:0]

P30 Function select

P3FSRL1

P3FSRL0

Description

I/O Port

TXD1/MOSI1 Function

SDA Function

EC2 Function
