Accu-Chek Inform II User Manual

44
08424705001 (01) 2017-04 USA • Accu-Chek Inform II Operator’s Manual Version 6
Closing startup Once you have completed all the necessary changes,
■ touch to proceed to the screen used to enter
the operator ID, or
■ wait 5 seconds and the meter automatically pro-
ceeds to the screen used to enter the operator ID.
2.2 Entering the operator ID
How and when an operator ID is entered and if a pass-
word is required, depends on the configuration of the
system. It is also, for example, possible to require the
operator ID only when starting control tests. In general,
the system can manage and check operator IDs as well
as make additional functions ID-dependent.
If an operator name matching the entered operator ID is
available on the meter, this name will be displayed in the
Main Menu (shown here as “Maria S.”).
There are a number of options for entering operator IDs
and these depend on the configuration of the system:
■ Via barcode scanner only (a list of supported
barcode symbologies can be found in Appendix
A.2)
■ Manually or optionally via barcode scanner
Operator IDs can consist of up to 20 alphanumeric
characters.
Alphanumeric characters are any combination of
A - Z and 0 - 9, additionally “.” (period), or “-” (hyphen)
may be used. See also page 46.
Barcode masking can be used to eliminate any charac-
ters not belonging to the Operator ID. See information
on “Operator and patient ID barcode masks” on
page 192.
Main Menu
Review Results
Control Test
Patient Test
Maria S.
12:48 pm
03/17/17

Accu-Chek Inform II Specifications

General

Sample Size	0.6 µL
Test Time	5 seconds
Memory Capacity	1000 test results
Display	LCD
Measurement Range	10 to 600 mg/dL
Connectivity	Infrared
Sample Type	Capillary whole blood
Operating Temperature	16 to 32°C (61 to 90°F)
Relative Humidity	10 to 90% non-condensing
