Accu-Chek Inform II User Manual

92
08424705001 (01) 2017-04 USA • Accu-Chek Inform II Operator’s Manual Version 6
The parameters for control solutions consist of four sepa-
rate values.
3 Use the keypad to enter the desired values one
after another:
– Minimum limit value for Level 1
– Maximum limit value for Level 1
– Minimum limit value for Level 2
– Maximum limit value for Level 2
4 Touch to confirm each separate entry and
continue to the next entry.
123
456
789
0
Control L2 Max
353 mg/dL
12:48 pm
.
03/17/17
123
456
789
0
Control L2 Min
261 mg/dL
12:48 pm
.
03/17/17
123
456
789
0
Strip Expiration
05/30/17
12:48 pm
03/17/17

Accu-Chek Inform II Specifications

General

Sample Size	0.6 µL
Test Time	5 seconds
Memory Capacity	1000 test results
Display	LCD
Measurement Range	10 to 600 mg/dL
Connectivity	Infrared
Sample Type	Capillary whole blood
Operating Temperature	16 to 32°C (61 to 90°F)
Relative Humidity	10 to 90% non-condensing
