165 Ag Leader PN 4002083 Rev. N
P
LANTING
A
UTO
S
WATH
PLANTING
AUTOSWATH
ROW SHUTOFF
Create an Implement configuration with Row Shutoff by following the procedure in “Create Planting
Configuration” on page 161
. By configuring your display with Row Shutoff, you can start and stop seed flow
and control planter sections row-by-row, allowing AutoSwath Control to automatically turn planter row
units on and off based on your planting map.
See
“Map Options” on page 51 for more information on using reference maps for AutoSwath.
CONFIGURATION SETUP
Once the configuration is created and it appears on the Configuration Setup screen, AutoSwath should
be configured correctly. However, if you cannot get the configuration to load on the Field Operation
Wizard, or if your vehicle does not appear on the Map screen, you may wish to check if the row clutches
have been correctly set up in Implement Setup. Use the following procedure to enable Seed Row Shutoff
and/or configure the Clutch Module.
Press: Home button > Setup (wrench) button > Configuration (tractor) button > Configuration tab > your
specific configuration > Setup (wrench) button > Row Shutoff button
The Row Shutoff Module Configuration screen appears. This screen shows the number of Row Shutoff
Modules and the sections that each module controls.
ROW SHUTOFF LOOK-AHEAD NUMBERS
This table references the Turn-On Look-Ahead and Turn-Off Look-Ahead numbers for both Electric
Clutch and Air Row Shutoff Modules.
Note: Using the above settings should produce good field results. However, always take the time to check for
proper seed placement in the field and make system setting adjustments as needed. Do not rely solely upon
the appearance of the On-Screen map. The on screen map will not show gaps and overlaps caused by
incorrect GPS Offsets or AutoSwath Look-Ahead settings.
Planter Unit Seed Meter Type On/Off Electric Clutch Air Clutch
Finger Units
Turn On 0.9 1.1
Turn Off 0.3 0.3
Vacuum
Turn On 0.9 1.1
Turn Off 0.4 0.4
Select Your Specific
Configuration
To Next Page
