173 Ag Leader PN 4002083 Rev. N
P
LANTING
R
ATE
C
ONTROL
HYDRAULIC SEED METER CALIBRATION NUMBERS
Prior to calibrating the Hydraulic Seed Meter, the numbers that appear in the Meter Calibration box in the
Planter Control window should be similar to the numbers that appear below. If they are not, the seed
meter may be working incorrectly, or the Gear Ratio may be incorrect. Contact Technical Support for
further assistance.
Note: Check the operator’s manual for more specific information on other seed disk options.
Planter brand and type
Corn Soybeans
Cotton
Standard
Rate
Sorghum
John Deere
Vacuum: Standard 30 108 64 45
Vacuum: ProMAXâ„¢ 40
Vacuum: Precision Planting eSet® 30
Vacuum: VenHuizen AccuVac Kit 40
Mechanical: Finger 12
Mechanical: Brush Meter 56
Case IH
Vacuum 48 130 80 80
Cyclo® 36 240
KINZE
EdgeVac® 39 60 54 60
Mechanical: Finger 12 60 30 60
White
30 60
Great Plains
Mechanical: Standard 12 110 120 102
Mechanical: Twin Row 6 100 135
To Next Page
