279 Ag Leader PN 4002083 Rev. N
A
PPLICATION
O
PT
R
X
Managed Rate - amount of nitrogen crop will uptake throughout a single season.
Number of Applications - times per season N will be top-dressed.
Planned Rate - intended rate to apply if sensors were not used.
Application Trend - setting telling system whether to Increase rate for High Biomass or Decrease rate
for High Biomass.
Sensor Setup
Sensor Setup screen appears. Each sensor is shown,
with the status of “ON” or “OFF”.
• Enable
Turns on the individual OptRx sensor.
• Disable
Turns off the individual OptRx sensor.
APPLICATION RATE TABLE
Press: Home button > Setup (wrench) button > Configuration (tractor) button > Configuration tab > your
specific configuration > Setup (wrench) button > Crop Sensor button > Use Application Rate Table
checkbox (Check)
Sensor
Status
Sensor Setup
1
2
3
4
5
6
7
8
9
10
ON
ON
ON
ON
ON
N/A
Enable
Disable
N/A
N/A
N/A
N/A
Select Your Specific
Configuration
Use Application
Rate Table
To Next Page
