298 Firmware Version 6.0
• Fan Speed Calibration
The number of pulses that are generated by the sensor
during one revolution of the spinner dish. The default
setting is 4.
• PWM Gain
Determines how aggressively the control valve
responds when making spinner speed adjustments. The
higher the value the more aggressive the system
response is. The default setting is 20.
• PWM Frequency
The frequency that the PWM control valve is pulsed at.
Settings can be found from the manufacturer of the
valve. Typical settings range from 100-125 Hz. The
default setting is 100.
• Zero RPM Offset
Represents the maximum duty cycle that is sent to the
control valve without producing any hydraulic flow from
the PWM valve. Using too high of a Zero RPM Offset
value can cause the spinner system to not properly shut
off. The default setting is 30.
Note: See the PWM valve manufacturer information for recommended settings.
• Automatic Control
Checking this box enables closed loop spinner control.
Beginning with the 5.4 display firmware upgrade, checking the Automatic Control
check box exposes a Spinner Icon in the Task Bar that allows user to turn on/off
spinners from the Map Screen. Automatic Control default setting is unchecked.
CREATING PRODUCTS
Creating application products including dry fertilizer blends can be completed upon initial setup or from
the Product Selection screen of the Field Operation Wizard when starting a field operation.
CREATING SINGLE PRODUCTS
To create a single product, to be added to a blend or to be applied by itself, use the on-screen wizard
described in the following steps.
Press: Home button > Setup (wrench) button > Configuration (tractor) button > Product tab > Add (+)
button > Application Product button
1. Select Product Type
Use drop-down menu to select Product Type.
Spreader Control
Channel 1
Channel 2
Channel 3
Spinner
Fan Speed
Calibration
PWM
Gain
PWM
Frequency
Zero RPM
Offset
Automatic
Control
4 pls/rev
20
100 Hz
30
