Ag Leader Integra Display User Manual

251 Ag Leader PN 4002083 Rev. N
A PPLICATION
L
IQUID
R
ATE
C
ONTROL
SERVO CONTROL VALVE SETTINGS (BY MANUFACTURER)
Flow Control Valve
Control Valve
Configuration
Valve Response
1
Valve Response
2
Response
Threshold
Raven Accu-Flow, 20
GPM Single Valve System
(Fast Close Valve)
In-line servo 40% 10% 5
Raven Accu-Flow, 10
GPM Dual Valve System
(Standard Valve)
In-line servo 100% 24% 5
Raven Accu-Flow, 30
GPM Single Valve System
(Fast Close Valve
In-line servo 40% 10% 5
Raven Accu-Flow, 30
GPM Dual Valve System
(Standard Valve)
In-line servo 100% 24% 5
Raven Flow Control Valve,
3/4" (Standard Valve)
In-line or Bypass
Servo
100% 24% 1
Raven Flow Control Valve,
3/4" (Fast)
In-line or Bypass
Servo
40% 10% 5
Raven Flow Control Valve,
1" (Standard)
In-line or Bypass
Servo
100% 24% 2
Raven Flow Control Valve,
1" (Fast)
In-line or Bypass
Servo
40% 10% 5
Raven Flow Control Valve,
1 1/2" (Standard)
In-line or Bypass
Servo
100% 24% 3
Raven Flow Control Valve,
2" (Standard)
In-line or Bypass
Servo
100% 24% 8
Raven Flow Control Valve,
2" (Fast)
In-line or Bypass
Servo
40% 10% 15
Raven Flow Control Valve,
3" (Standard)
In-line or Bypass
Servo
100% 24% 15
Mid-Tech, 3/4”
In-line or Bypass
Servo
40% 10% 5
Mid-Tech, 1”
In-line or Bypass
Servo
40% 10% 8
Mid-Tech, 1 1/2”
In-line or Bypass
Servo
40% 10% 11
Mid-Tech, 2”
In-line or Bypass
Servo
40% 10% 15
