9 Ag Leader PN 4002083 Rev. N
G
ENERAL
I
NSTALLATION
FUSE INSTALLATION AND REPLACEMENT
Fuse Type: Blade Style (ATO/ATC)
Rating:
Fuse Holder (orange wire) 5A, 250 VAC
Fuse Holder (pink wire) 15A, 250 VAC
CAUTION: The fuse is to be placed in the fuse holder in-line with the battery power cable and used with
display only.
SCREEN ICON CONVENTIONS
The following control buttons are made available for entering names and calibration values into the
system.
