306 Firmware Version 6.0
Spreader Control: Static Calibration
You must perform a conveyor discharge calibration for each granular product control channel (bin) for
the equipment configuration. This process is outlined below and on the following page. The static
calibration procedure is performed before applying in field conditions.
1. Press Spreader Control button
To begin, press the Spreader Control button on the Map screen. The Spreader Control
screen opens.
2. Start Calibrate Conveyor routine
Press the Static Calibration button to start the Static Conveyor Rate calibration routine.
3. Disable Spinner Hydraulic Circuit
The system will present a warning to disable the spinner hydraulic circuit. Press after the hydraulic
circuit is disabled.
WARNING: Manually disable or shut off the spinner hydraulic circuit. If the spinner runs unexpectedly, injury
could occur.
4. Select Conveyor to Calibrate
Press to continue.
5. Enter Dispense Amount
Enter the desired target amount of product to dispense (the recommended amount is 500 pounds or 250
kilograms). Press to continue.
6. Start Dispensing Product
Press the Start button to begin dispensing the product.
7. Product Dispensing
The conveyor will stop when the system perceives the target amount of product has been dispensed. The
Stop button can be pressed at any time to manually shut off the conveyor.
8. Product Dispensing Stops
On the screen shown after dispensing the display’s target amount, value can be reset and the process
started again for a larger sample size, if desired. Press to continue.
9. Enter Actual Dispense Amount
Enter the actual weight of the product dispensed. Press to continue.
10. Finish Calibration
A screen displays, stating Calibration Complete and underneath is shown the newly-calibrated conveyor
rate.
- Press to exit the calibration without saving the value.
- Press Repeat Calibration to begin the process again.
- Press to save the value and exit the calibration routine.
11. Restart spinner hydraulic circuit
Restart the spinner hydraulic circuit.
