224 Firmware Version 6.0
9. Assign Container Capacity
Press to enter the container capacity. Press to accept.
10. Enter Container Units
Use the drop-down menu to select the container units.
Once container has been configured press to continue.
11. Enter Swath Width
Press to enter swath width.
12. Enter Number of Boom Sections
Press / to enter number of boom sections.
13. Enter Boom Section Widths
Highlight specific boom section and p
ress to enter boom width. The total width of all boom
sections must equal swath width.
14. Enter Application Point Offset
Press to enter distance from hitch to application point (front to back). Press to accept
value on offset screen. Press to accept value for the application point.
Note: If setting up a Self-Propelled Applicator, enter the distance from rear axle to application point.
Use drop-down menu to select distance Behind or In Front.
Note: At this point additional functionality can be added to the implement, such as direct injection.
If no additional functionality is being added, press to continue.
15. Add Additional Devices (optional)
Press to add boom control functionality.
Press to add boom sensor functionality.
• Press to enter sensing width (defaults to implement width, change only if necessary).
• Use / to enter number of sensors.
• Press Swath Offsets button to enter offsets. System can not be configured with sensors and application
point on opposite sides of the hitch.
Press to continue.
