Ag Leader Integra Display User Manual

254 Firmware Version 6.0
*Adjust this number to fit your particular configuration.
**If you are using a PWM control valve, some adjustment may need to be made to achieve optimal pump
response to the PWM gain value. Increase the Gain value to make the system more responsive;
decrease the Gain value to smooth the system response.
Miller Nitro N4 Pump Servo 2% 100% 24% 12
Montana Paruda Calibrated Reflow 2% 100% 40%
2
(Imperia
l) or
11.4
(Metric)
RoGator 864, 874,
1064, 1074
PWM Ground 122
**500-
700
30 2%
RoGator 1054 Pump Servo 2% 100% 24% 3
RoGator 1254 Pump Servo 2% 100% 24% 3
RoGator 1264,
1274 (up to 2006)
PWM Ground 122
**500-
700
30 2%
RoGator 1274,
1286, and SS
Series (2007 and
up)
PWM Ground 122
**500-
700
30 2%
Spra-Coupe 3X40,
3X50, 4X40, 4X50
In-Line Servo 2% 100% 24% 3
Spra-Coupe 7000
with factory pump
switch
PWM Ground 122
**500-
700
30 2%
Spra-Coupe
without factory
pump switch
PWM Ground 122
**500-
700
30 2%
TerraGator XX03,
XX04, XX44
In-Line Servo 2% 40% 10% 15
Tyler Patriot,
Patriot II, XL, 150,
150XL and WT
Check for In-Line
Servo or By-Pass
Servo Control
2% 100% 24% 3
Walker Pump Servo 2% 100% 24% 3
Flow Control Valve
or Sprayer Model
(and year if
applicable)
Control System
PWM Frequency
Typical Gain Range
Zero Offset
Allowable Error
Valve Response
1
Valve Response
2
Response Threshold
