The Strip Till Control screen appears.
Press the Prime button to access the Air Cart Prime
screen.
The Air Cart Prime screen appears with input
buttons for each channel used. The setting
determines the revolutions necessary to prime the
meter shaft. Settings are independent by channel,
and can be entered using .
(A) Start Prime
(B) Channel 1 Revolutions
(C) Channel 2 Revolutions
(D) Channel 3 Revolutions
Note: Meter Prime routine is not available and remains hidden for ground driven metering configurations.
Channel 1
Channel 2
Channel 3
MAP
Product
Density
Conveyor 1
Rate
62 lb/ft3
0 ft3/rev
Static
Calibration
In-Field
Calibration
Prime
Strip Till Control
Channel 1
Revolutions
0.25
Channel 2
Revolutions
0.25
Channel 3
Revolutions
0.25
1
2
3
Start
Prime
Air Cart Prime
Strip Till Control
Channel 1
Channel 2
Channel 3
Auxiliary
Control Valve Configuration
Single Bin Actuator
Allowable
Error
2 %
Shaft Speed
Calibration
180 pls/rev
Max Metering
Speed
100 rpm
Actuator
Response 1
90 %
Actuator
Response 2
18 %
Response
Threshold
4
