Agilent Technologies 1220 Infinity II LC User Manual

1220 Infinity II LC System User Manual 157
Test Functions and Calibration
9
Autosampler
vial positions on the tray. When the correction calculation is complete, the
values for both X and theta are rounded to one decimal place. On completion
of the alignment procedure, the corrected gripper positions are stored in the
module's firmware.
ALS Alignment Controls
NOTE
To ensure correct operation of the autosampler, the alignment procedure must be carried
out in the correct sequence and in full (that is, without skipping any part).
Button Description Keyboard Shortcut
Rotate the gripper by
increasing theta.
Cursor Up
Move the gripper horizontally
to the left.
Cursor Left
Move the gripper horizontally
to the right.
Cursor Right
Rotate the gripper by
decreasing theta.
Cursor Down
Arm Up Lifts the gripper arm. Page Up
Arm Down Lowers the gripper arm. Page Down
Open Gripper Opens the gripper.
Close Gripper Closes the gripper.
Start >> Starts the execution of the
procedure. Shown only at the
start.
Enter
Continue >> Jumps to the next step of the
procedure. Shown only during
alignment.
Enter
Restart Restarts the execution of the
step.
