Agilent Technologies 8453 User Manual

55
Theory of Operation
External Cables
Table 8 General Purpose Cable (G1103-61611)
Pin Function Pin Function
1 OUT [0] 9 IN [0]
2 OUT [1] 10 IN [1]
3 OUT [2] 11 IN [2]
4 OUT [3] 12 IN [3]
5 OUT [4] 13 IN [4]
6 OUT [5] 14 IN [5]
7OUT [6] 15DGND
8OUT [7]
