148
Interfacing
Setting the 8-Bit Configuration Switch
If you use the following switch settings and power the instrument up again,
the instrument firmware stays in the resident part, that is, it is not operable as
a spectrophotometer, but only uses basic functions of the operating system,
for example, for comunication and so on.
To return to normal operation, set switches back to your GPIB or RS 232
configuration settings.
Comunication Settings for RS232 Comunication
The comunication protocol used in this instrument supports only hardware
handshake (CTS/RTR).
Switches 1 in down and 2 in up position define that the RS232 parameters will
be changed. Once the change has been completed, the instrument must be
powered up again in order to store the values in the non-volatile memory.
Use the following tables for selecting the setting which you want to use for
RS232 comunication. The number 0 means that the switch is down and
Table 55 Stay Resident Settings
Mode Select12345678
TEST/BOOT11001000
Table 56 Communication Settings for RS232 Communication
Mode Select12345678
RS-232 0 1 Baudrate Data Bits Parity
