1 Introduction
6 N1911A/1912A P-Series Power Meters User’s Guide
These keys are located along the lower edge of the display.
Key Function
Press this key to access general configuration-menus, such as GPIB
address. You can also access the Self-Test and Table entry menus.
The measurement screen remains visible.
Press this key to access the channel configuration menus. Channel
parameters such as averaging and offsets are configured from this
menu.
Press this key to access the triggering menu. Unless a P-Series or an
E-Series E9320A Sensor is connected, all the menu keys are disabled
(grayed out).
Press this key to setup relative measurements or set display offsets.
Use this key to configure the selected measurement.
Press this key to access the measurement display menu. You can
choose the displayed measurement resolution, units and display
format.
Use this key together with to configure measurement
displays.
