Table 2- 6 shows the available measurement functions during normal and
average mode when in power or frequency sweep.
Table 2 - 6 Power and frequency sweep measurement functions table
Power Sweep Mode
Power sweep is generally used in power level calibration setup where the
frequency is fixed, and the amplitude of the power source signal is swept.
This mode can be used to characterize the flatness, linearity or gain
compression of a device under test.
Procedures
1 Connect sensor to a power source.
2 Connect power meter TRIG OUT to power source TRIG IN using a
BNC cable. The same connection is applied for power source TRIG OUT
to power meter TRIG IN. See Figure 2- 58 on page 84.
Measurement functions Normal Mode Average Mode
Hold off
✔
—
Trigger delay
✔
—
Measurement averaging —
✔
Gate setting
✔
—
Channel offset —
✔
Hysteresis — —
Measurement types
supported
Peak, peak-to-average,
average, minimun power
Average only
Refer to the P-Series Power Meters Programming Guide for the commands usage details.
Example of command set:
SENSe:BUFFer:MTYPe “PEAK”
This feature is applicable for 8480 Series, N8480 Series, E-Series E4410, E-Series E9300,
E-Series E9320 or P-Series N1920 sensor when connected.
