Agilent Technologies N1911A - Figure 2-65 Minimum Limit Pop-Up

2 General Power Meter Functions
88 N1911A/1912A P-Series Power Meters User’s Guide
5 Press to display the Minimum Limit pop- up.
Figure 2-65 Minimum limit pop-up
6 Use the numeric keys to enter the required value and press .
7 Use the key to highlight the Maximum Limits: value field.
8 Press to display the Maximum Limit pop- up.
9 Use the numeric keys to enter the required value and press .
10 Press key to close the Measurement Setup screen.
dBm
dBm
NOTE
The Limits can be disabled and re-enabled by checking the Limits: setting field.
