Agilent Technologies N1911A - Figure 2-28 Frequency Dependent Offset Tables Display

2 General Power Meter Functions
44 N1911A/1912A P-Series Power Meters User’s Guide
Procedure
Select an offset table as follows:
1 Press, either:
a. , , .
b. , and use the and keys to highlight the FDO
Tabl e
setting field and press to display the table.
Figure 2-28 Frequency dependent offset tables display
2 Use the and keys to highlight one of the 10 table titles and press
to highlight .
3 Press to complete the selection of the offset table.
4 Press again to display the measurement screen. Figure 2- 29
shows which offset table is selected.
Tables
Freq. Dep. Offset
Offsets
Table
On
NOTE
When no data is contained in the highlighted table, the key is disabled (grayed out).
Table
Done
Done
