Agilent Technologies N1911A - Figure 2-70 Function Pop-Up; Figure 2-71 Measurement Type Pop-Up

General Power Meter Functions 2
N1911A/1912A P-Series Power Meters User’s Guide 93
2 Press to display the Function pop- up, and use the and
to highlight Single.
Figure 2-70 Function pop-up
3 Press to complete the entry.
4 Use the , , , , to highlight the measurement type field.
5 Press to display the Feed Measurement pop- up, and use the
and in assign a measurement type.
Figure 2-71 Measurement type pop-up
6 Press to complete the entry.
7 Use the , , , , to highlight the Gate field.
