2 General Power Meter Functions
104 N1911A/1912A P-Series Power Meters User’s Guide
Saving and Recalling Power Meter States
To reduce repeated setup sequences, you can save a maximum of ten
power meter states in the non- volatile memory.
The save/recall functions are part of the Sys/Inputs menu, accessed by
pressing the key.
To save a measurement setup:
1 Press , to display the Save/Recall screen as shown
in Figure 2- 83.
Figure 2-83 Save/Recall screen
2 Using the and keys, select an available name from the displayed
list. To change the name of a register - See Chapter 2, “Editing a
Register’s Name,” starting on page 105, otherwise press .
Your power meter has measurement configurations suitable for common wireless
communication and radar (pulse) formats already saved as Instrument Presets. These
require P-Series or E-Series E9320 power sensors.
