Using 8480 Series Power Sensors 7
N1911A/1912A P-Series Power Meters User’s Guide 185
Procedure
First select the table for the sensor you are using as follows:
1 Press , , .
2 Use the and keys to highlight one of the 20 table titles and press
to highlight .
Figure 7-128Sensor table selected
3 Press to complete the selection of the calibration factor table.
4 Press again to display the measurement screen. Figure 7- 129
shows which offset table is selected.
Figure 7-129Frequency dependent offset indicator
Tables
Sensor Cal Tables
Table
On
NOTE
When no data is contained in the highlighted table, the key is disabled (grayed out).
Table
Done
Done
Sensor Table 2 Selected
