Agilent Technologies N1911A User Manual

General Power Meter Functions 2
N1911A/1912A P-Series Power Meters User’s Guide 61
Figure 2-43 Marker 2 Ref Percentage pop-up
5 Use the numeric keys to complete the entry and press softkey.
Figure 2-44 The placement of gates (markers) in Auto Gating mode
%
Pulse Duration (PD)
Ref 1 x PD
Ref 2 x PD
NOTE
Enabling the softkey allows the gates to be repositioned automatically
according to the changes of pulse duration.
Perpetual Off On
