General Power Meter Functions 2
N1911A/1912A P-Series Power Meters User’s Guide 35
6 Press the , , key to highlight the Rel field.
7 Press and the original result value will appear on the right hand
side of the Rel check field.
8 The relative value displayed under Result field will change as the
measured signal varies.
If you return the power meter to display the numeric display, a Rel symbol will be displayed
in the measurement window it is applied to.
Figure 2-18 Numeric display
The Rel symbol is not displayed when the associated measurement is displayed in Dual
Numeric or Analog format.
