2 General Power Meter Functions
96 N1911A/1912A P-Series Power Meters User’s Guide
5 Press to display the Feed Measurement pop- up (see Figure 2- 71)
and use the and in assign a measurement type.
6 Press to complete the entry.
7 Use the , , , , to highlight the Gate field.
8 Press to display the Gate Number pop- up, see Figure 2- 72, and
use the numeric keypad to enter the required value in the Gate Number
pop- up window.
9 Press to complete the entry.
10 Repeat this process until you have setup all the required gates and
measurements.
11 Press key to complete the setup and display the measurements
results.
Figure 2-74 Measurement example display
Enter
