Agilent Technologies N1911A - Figure 9-152 Scale;DIV Pop-Up

CCDF 9
N1911A/1912A P-Series Power Meters User’s Guide 225
Figure 9-152Scale/Div pop-up
Step 4: Store the Trace for Reference
• The function of is to save the trace of either Channel
A or Channel B into the volatile memory of the power meter.
• Press under the menu to retrieve the stored
trace.
Store to Reference
Reference
Trace Display
