General Power Meter Functions 2
N1911A/1912A P-Series Power Meters User’s Guide 43
To use frequency dependent offset tables:
1 Select the table to be applied to a channel. Refer to “Setting Frequency
Dependent Offsets” on page 42 for further information. If you require to
edit the table refer to “Editing Frequency Dependent Offset Tables” on
page 45 for further information.
2 If using an 8480 Series, N8480 Series or an E- Series sensor, zero and
calibrate the power meter. The reference calibration factor used during
the calibration is automatically set by the power meter from the sensor
calibration table (if selected).
3 Specify the frequency of the signal you want to measure. The
calibration factor/offset is automatically set by the power meter from
the sensor calibration table (if selected) and the frequency dependent
offset table. Refer to “Procedure” on page 44 for further information.
4 Make the measurement.
Selecting a Frequency Dependent Offset Table
You can select a frequency dependent offset table from the key
menu followed by and .
The State column indicates if any frequency dependent offset tables are
currently selected. The Offset Tables screen is shown in Figure 2- 28.
You can also view which FDO table is being used by pressing the ,
and use the and keys to highlight the FDO Table setting field and press to
display the table.
