EFFECTS
S2000 Operator’s Manual - Version 1.30 Page 157
EFFECTS MODE
With the optional EB16 installed, the EFFECTS key gives access to the S2000’s internal
effects. The S2000’s effects processor is a 4 channel effects processor. Two channels (FX1
and FX2) offer multi effects that include distortion, ring modulation, EQ, modulation effects
such as flanging, chorus and phasing, stereo pitch shift, autopanning, rotary speaker
simulations plus delay/echo and reverb. The other two channels are reverb only channels
(RV3 and RV4) giving a total of four reverbs.
DISTORTION EQ RING MOD
CHORUS
FLANGE
PHASE
PITCH SHIFT
PAN/FMOD
DELAY REVERB
MOD/DELAY EFFECTS REVERB (RV1)DISTORTION/EQ
MULTI-EFFECTS CHANNEL FX1
REVERB
REVERB
REVERB ONLY CHANNEL RV3
4-CHANNEL EFFECTS PROCESSOR
or
or
or
or
DISTORTION EQ RING MOD
CHORUS
FLANGE
PHASE
PITCH SHIFT
PAN/FMOD
DELAY REVERB
MOD/DELAY EFFECTS REVERB (RV2)DISTORTION/EQ
MULTI-EFFECTS CHANNEL FX2
or
or
or
or
REVERB
REVERB
REVERB ONLY CHANNEL RV4
