EFFECTS EDIT
Page 184 S2000 Operator’s Manual - Version 1.30
PING PONG ECHO EFFECTS
The next page down allows you to add another repeat element to the echo effect:
The L/R OFFS(et) parameter takes a ‘tap’ off the delayed signal to produce a secondary repeat.
This allows you to create pseudo stereo ‘ping pong’ echo effects that bounce back and forth
from left to right. Depending on the setting of this control you can create ‘ping pong’ echos of
equal length but you may also create ‘asymmetric’, syncopated ‘ping pong’ effects.
LEFT
RIGHT
IN
500mS 1Sec 1.5Sec
250mS 750mS 1.25Sec
With L/R OFFS(et) settings of, say, ±25, the first repeat will come after 125mS, the second
after 500mS, the third after 625mS, etc. (depending on the amount of feedback). I.e.
RIGHT
IN
500mS 1Sec 1.5Sec
LEFT
125mS 625mS 1.125Sec
The closer the L/R DELAY OFFSET parameter is set to ±50, the closer the first echo will be to
the value set in the FBK parameter seen on the previous page.
The OUTPUT field selects where you will listen to the output of the delay and allows you to set
the direction of the modulation section and the echo section. You may select POST which will
give the effect of echo followed by the mod effects or you may select PRE which will give the
effect of the mod effects followed by echo.
NOTE: When PRE is selected, you must set a value in the FBK parameter on the previous
page to hear any delay effect
NOTE REGARDING MONO ECHO EFFECTS
Please note that because the stereo mod section passes through the echo section, any
stereo mod effects you create will be ‘monofied’ when mono delay effects are selected. To
enjoy stereo modulation effects with echo, please choose the stereo delay option (see
below).
